3.3.2 Inspecting, oil level gearbox axes 2 - 3
Location of gearbox, axes 2-3
The gearboxes axes 2-3 are located in the lower arm rotational center, underneath
the motor attachment.
xx0500002482
Gearbox, axis 2A
Oil plug, drainingB
Oil plug, fillingC
Ventilation hole, gearbox axis 2D
