NoteAction
Tightening torque on lock nuts:
• 120 Nm
Apply locking liquid on the lock nuts (KM10).
Note
Do not apply locking liquid on the shafts!
9
Minimum play:
• 0.1 mm
Check play between support washer and bearings at
both bearings.
10
Lubricating, piston rod
Use this procedure to lubricate the balancing device piston rod.
NoteAction
Move axis 2 to a position where the balancing device
is in horizontal position and the piston rod extended
as much as possible.
1
DANGER
Turn off all:
• electric power supply to the robot
• hydraulic pressure supply to the robot
• air pressure supply to the robot
Before entering the robot working area.
2
Clean piston rod with isopropanol before applying
new grease.
3
Type of grease is specified in
Required equipment on page 167.
Apply new grease.4
168 Product manual - IRB 6660
3HAC028197-001 Revision: S
© Copyright 2007-2018 ABB. All rights reserved.
3 Maintenance
3.5.1 Lubricating balancing device bearings and piston rod
Continued
