Base plate, orienting grooves and leveling bolts
The illustration below shows the orienting grooves and attachment holes for leveling
bolts in the base plate.
A
A
A
B
B
B
B
xx1500000312
Orienting grooves (3 pcs)A
Levelling bolts, attachment holes (4 pcs)B
Continues on next page
78 Product manual - IRB 6660
3HAC028197-001 Revision: S
© Copyright 2007-2018 ABB. All rights reserved.
2 Installation and commissioning
2.3.6 Securing the base plate
Continued
