Hole configuration, base
This illustration shows the hole configuration used when securing the robot.
xx0300000046
Cross section, guide sleeve hole
This illustration shows the cross section of the guide sleeve holes.
xx0100000109
Product manual - IRB 6660 83
3HAC028197-001 Revision: S
© Copyright 2007-2018 ABB. All rights reserved.
2 Installation and commissioning
2.3.7 Orienting and securing the robot
Continued
