ABB IRB 6660 - Page 92

NoteArticle numberEquipment
Loctite 243. Used for the three tightening
screws.
-Locking liquid
Content is defined in section Standard
tools on page 381.
-Standard toolkit
See chapter Circuit diagram on page 389.3HAC025744-001Circuit diagram
These procedures include references to
the tools required.
Other tools and procedures
may be required. See refer-
ences to these procedures
in the step-by-step instruc-
tions below.
Plate for customer connections, at base
xx0500002301
Plate for customer connectionsA
Attachment screws, 3 pcs, M6x16 quality 8.8-A2FB
