3 System Description
3.2 Basic Design
24 3HNA009834-001 en Rev.06 Product Manual, Control Cabinet IRC5P
Figure 8 Pendant identification label
Figure 9 TIB adapter identification label
0470
APPROVED
SER.NO
N-4349 Bryne, Norway
AS Robotics
Nordlysvegen 3
WARNING! Substitution of components may impair intrinsic safety
PTPU-01 3HNA006148-001
Ta: 10°C....+40
NEMKO 08ATEX1188
IECEx NEM 08.0003
Instrinsically safe apparatus for
Cl. 1, Div. 1, Gr. C & D T4
135°C
II 2 G, Ex ib IIB T4
0470
APPROVED
NEMKO Nr.Ex 08ATEX1188
[Ex ib] IIB
for Cl.1, Div.1,Gr. C & D
Drawing 3HNA012823-001
II 2 G
Box 265, N-4349 Bryne, NORWAY
ABB AS, Robotics
Intrinsically Safe Outputs
in accordance with
U =50V
M
U1
C /uF
o
I A
o
U V
o
L /mH
o
7V 0.07 300 25
IIB
U2
7V 0.0214 300 250
U3 13.8V 0.894 4.9 0.4
U4
14.8V 0.033 3.76 120
U5
14.8V 0.110 3.76 10
X4
X6
TYPE TIB
ITEM No. 3HNA006149-001
SERIAL No.
IECEx NEM 08.0003
