ABB IRC5P User Manual

3 System Description
3.2 Basic Design
26 3HNA009834-001 en Rev.06 Product Manual, Control Cabinet IRC5P
Figure 12 DSIB identification label
0470
APPROVED
Type: DSIB
3HNA012319-001
BatchSerial No.
[EEx ib] IIB Tamb. 60°C,
NEMKO 04ATEX1243
Intrinsically Safe Outputs,
Ref. Dwg. No.: 3HNA015815-001
II (2) G,D
PO Box 265, N-4349 Bryne NORWAY
ABB AS, Robotics
Class I,II Div.1,
Um=250V, Un=24VDC,
Vo=12.3V, Io=13.7mA,
Po=42mW
Group IIB, Ca/Co=16.2uF,
La/Lo=600mH
Warning:
Substitution of components may
impair intrinsic safety.
Must only
be used with ABB Robots.
X6X7
X5 X1
X8
Group C,D,G
