150 FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | OI/FEP630/FEH630-EN REV. D
… 15 Appendix
… Torque information
Nominal diameter [mm (in)]
Pressure rating Hard / soft rubber PTFE
** [Nm] *** [Nm] ** [Nm] *** [Nm]
DN 200 (8 in) PN10 — — 123.6 123.6
PN16 — — 113 116.9
PN25 — — 70.42 73
PN40 — — 109.9 112.5
CL150 — — 208.6 136.8
CL300 — — 158.1 158.1
DN 250 (10 in) PN10 — — 86.06 89.17
PN16 — — 99.42 103.1
PN25 — — 166.5 133.9
PN40 — — 279.9 241
CL150 — — 146.1 148.3
CL300 — — 246.4 246.4
DN 300 (12 in) PN10 — — 91.29 94.65
PN16 — — 113.9 114.8
PN25 — — 151.1 106.9
PN40 — — 254.6 252.7
CL150 — — 203.5 198
CL300 — — 421.7 259.1
DN 350 (14 in) PN10 — — 72.49 75.22
PN16 — — 124.9 104.4
PN25 — — 226.9 167.9
CL150 — — 270.5 263
CL300 — — 463.9 259.4
DN 400 (16 in) PN10 — — 120.1 113.9
PN16 — — 191.4 153.8
PN25 — — 404 246.7
CL150 — — 229.3 222.8
CL300 — — 635.8 328.1
DN 450 (18 in) CL150 — — 267.3 192.3
CL300 — — 660.9 300
DN 500 (20 in) PN10 — — 153.9 103.5
PN16 — — 312.1 224.8
PN25 — — 477.1 286
CL150 — — 237.3 230.4
CL300 — — 786.8 363.1
DN 600 (24 in) PN10 — — 238.7 149.1
PN16 — — 496.7 365.3
PN25 — — 750.7 539.2
CL150 — — 451.6 305.8
CL300 — — 1376 587.4
** Flange material: steel.
*** Flange material: stainless steel.
