FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | OI/FEP630/FEH630-EN REV. D 87
Menu: Display
Menu / parameter Description
Display
Language Selection of menu language.
(German, English, French, Spanish, Italian, Chinese, Portuguese).
Contrast Contrast setting for the LCD display.
...Operator Page 1 Selection of submenu ‘...Operator Page 1’ using .
...Operator Page 2 Selection of submenu ‘...Operator Page 2’ using .
Autoscroll If Autoscroll is enabled, the ‘Autoscroll’ function can also be activated on the information level of the operator menu.
In this function, operator pages are automatically displayed in succession on the process screen, changing every 10
seconds. Manual scrolling through pre-configured operator pages as described above is no longer necessary. When Auto
scroll mode is enabled, the icon is displayed in the lower left corner of the screen.
Default setting: Disabled.
Flow Format Selection of number of decimal places (maximum 6) used to display the corresponding process variables.
Default setting: X.XX.
Tot Format
Date Format Set the display format for the date and time.
Display Tag Configuration of the top line in the display.
Off, Sensor Location Tag, Bus Address, HART Address
Display Rotation The display on the display can be rotated through software by 180°.
Display Test Start the test of the LCD display with ‘ ’. The display test lasts approx. 10 seconds. Various patterns are shown on the
LCD display to check the display.
Display / ...Operator Page 1 (n)
Display Mode Configure each operator page.
The following versions can be selected:
Off, Graph View, 1x4, 1x6A, 1x6A Bar, 1x9, 1x9 Bar, 2x9, 2x9 Bar, 3x9.
Selecting ‘Off’ deactivates the corresponding operator page.
1st Line Selection of process variable displayed in the respective row.
2nd Line • Qv [unit]: Volume flow rate in the selected unit.
• Qv [%]: Volume flow in %
• ∑V+: Volume totalizer forward
• ∑V-: Volume totalizer reverse
• ∑Vn: Volume totalizer net
• CO1 Current: Output current in mA
• Qm [unit]: Mass flow in the selected unit.
• Qm [%]: Mass flow in %
• ∑M+: Mass totalizer forward
• ∑M-: Mass totalizer reverse
• ∑Mn: Mass totalizer net
• scaled velocity: Flow velocity
3rd Line
Bargraph Selection of process variable displayed as a bar graph.
• Qm [%]: Mass flow in %
• Qv [%]: Volume flow in %
• CO1 Current: Output current in mA
