ABB ProcessMaster FEP630 series User Manual

114 FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | OI/FEP630/FEH630-EN REV. D
… 9 Diagnosis / error messages
Overview
Errors encountered are itemized in tabular form on the following pages. The response of the transmitter on error detection is
described therein.
The table lists all possible errors together with a description of their impact on the value of measurement variables, the properties of
current outputs and the alarm output.
Error no. / Range Error text Current output Digital output Pulse output LCD display Error maskable?
F099.042 /
electronics
ADC overrange alarm.
Noise too high. Check applicati.
Call service.
High Alarm or Low
Alarm, depending on
parameter ‘Curr.Out
at Alarm’.
General Alarm if DO
as ’Logic / Alarm
Signal’ is configured
0 Hz 0 % No
F099.011 /
electronics
No Frontend Board detected.
Wrong connection. Defect
Frontend. Check wiring.
0 Hz 0 % No
F097.029 /
Electronics
Coil regulation error.
Check wiring of sensor coils.
Call service
0 Hz 0 % No
F096.043 /
Electronics
SIL self check alarm.
Call service.
Current value - no
change.
Current value - no
change.
No
F095.036 /
Electronics
Coil isolation alarm.
Call service.
Current value - no
change.
Current value - no
change.
No
F094.021 /
electronics
Safety Alarm Curr. Out 31 / 32
SIL function detects error. Call
Service.
Current value - no
change.
Current value - no
change.
No
F093.032 /
Electronics
Electrode short cuircit.
Check wiring of sensor
electrode. Call service.
0 Hz 0 % No
F092.033 /
Electronics
Electrode open cuircit.
Check wiring of sensor
electrode. Call service.
0 Hz 0 % No
F091.030 /
Electronics
Coil wiring error.
Check wiring of sensor coils.
Call service.
0 Hz 0 % No
