FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | OI/FEP630/FEH630-EN REV. D 71
Input/Output ...Curr.Out 31/32 Output Value
Curr.Out Mode
...Dig.Out 41/42 Curr.Out at Alarm
Low Alarm
...Dig.Out 51/52 High Alarm
Curr.Out > 20.5mA
Curr.Out < 3.8mA
Curr. at EPD Alarm
Curr. at TFE Alarm
Mode
Outp. Flow Direction
...Setup Pulse Output
Output Value Pulse
Pulses per Unit
Pulse Width
...Setup Freq Output Output Value Freq.
Upper Frequency
...Setup Logic Output
Logic Output Action
...Alarm Config Active Mode
General Alarm
Qv Volumeflow Max
Qv Volumeflow Min
EPD Alarm
TFE Alarm
Gas Bubble
Conductivity
Mode Sensor Temperature
Outp. Flow Direction
...Setup Logic Output Logic Output Action
Active Mode
...Alarm Config
General Alarm
Qv Volumeflow Max
Qv Volumeflow Min
EPD Alarm
TFE Alarm
Gas Bubble
Conductivity
Sensor Temperature
