Apparatus control
ABB Network Partner AB
1MRK 580 150-XEN
Page 6 - 49
Version 1.0-00
Fig. 38 shows the configuration of single outputs used for purposes other
than operating high-voltage apparatuses. Here the ERROR signal is con-
nected to an event function block for alarming or as a condition for
another application. The security is limited compared to the solutions
above - with two contacts in serial.
Fig. 38 Single output commands
I/O-module
BO1
BO2
BO3
BO4
BO.01
BO.02
Binary
Output
Module
XA
1
2
3
Switchyard/
Application software
+
-
.
.
.
BO24
-
On/Off
On/Off
control room
ERROR
For alarming
(X80150-38)
