ABB Network Partner AB
Apparatus control
Version 1.0-00
1MRK 580 150-XEN
Page 6 - 62
7.2 Signal list
7.2.1 BAYCONA
Table 1: Input signals for BAYCONA
IN: DESCRIPTION:
BAxx-S_R Input to change operator place to Remote
(pulse input)
BAxx-S_S Input to change operator place to Station
(pulse input)
BAxx-L_L Input to change operator place to Local
BAxx-RQ_SEL1 Request for selection and reservation of
apparatus 1
BAxx-RQ_SEL2 Request for selection and reservation of
apparatus 2
BAxx-RQ_SEL3 Request for selection and reservation of
apparatus 3
BAxx-RQ_SEL4 Request for selection and reservation of
apparatus 4
BAxx-RQ_SEL5 Request for selection and reservation of
apparatus 5
BAxx-RQ_SEL6 Request for selection and reservation of
apparatus 6
BAxx-RQ_SEL7 Request for selection and reservation of
apparatus 7
BAxx-RQ_SEL8 Request for selection and reservation of
apparatus 8
BAxx-BLK_RE Input for blocking all reservations
BAxx-OVERRIDE Input for overriding the reservation function
including the blocking by BLK_RE
BAxx-RE_B1 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 1
BAxx-RE_B2 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 2
BAxx-RE_B3 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 3
BAxx-RE_B4 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 4
BAxx-RE_B5 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 5
BAxx-RE_B6 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 6
BAxx-RE_B7 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 7
BAxx-RE_B8 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 8
BAxx-ACK_F_B Input for acknowledging the reservation of
other bays
