Apparatus control
ABB Network Partner AB
1MRK 580 150-XEN
Page 6 - 63
Version 1.0-00
BAxx-ANY_ACK Input indicating that at least one acknowl-
edge is still active
BAxx-V_TX Indication for valid transmission of the reser-
vation signals
BAxx-EX_DA_UP Input is 1 if the program that acknowledged
the reservation is running
BAxx-RE_RQ_B Request for reservation from other bays
BAxx-V_RE_RQ Input is 1 for valid request of reservation
from any bay
Table 2: Output signals for BAYCONA
OUT: DESCRIPTION:
BAxx-REMOTE Indication of Remote operator place
BAxx-STATION Indication of Station operator place
BAxx-LOCAL Indication of Local operator place
BAxx-SEL1 Apparatus 1 is selected after reservation
acknowledgement from other bays
BAxx-SEL2 Apparatus 2 is selected after reservation
acknowledgement from other bays
BAxx-SEL3 Apparatus 3 is selected after reservation
acknowledgement from other bays
BAxx-SEL4 Apparatus 4 is selected after reservation
acknowledgement from other bays
BAxx-SEL5 Apparatus 5 is selected after reservation
acknowledgement from other bays
BAxx-SEL6 Apparatus 6 is selected after reservation
acknowledgement from other bays
BAxx-SEL7 Apparatus 7 is selected after reservation
acknowledgement from other bays
BAxx-SEL8 Apparatus 8 is selected after reservation
acknowledgement from other bays
BAxx-RE A reservation has been made in this bay
BAxx-RE_BAYS Request for reservation of other bays
BAxx-ACK_T_B Acknowledgement to other bays that this
bay is reserved
BAxx-AU_OP_V1 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 1
BAxx-AU_OP_V2 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 2
Table 1: Input signals for BAYCONA
IN: DESCRIPTION:
