Apparatus control
ABB Network Partner AB
1MRK 580 150-XEN
Page 6 - 65
Version 1.0-00
7.2.2 BAYCONB
Table 3: Input signals for BAYCONB
IN: DESCRIPTION:
BBxx-S_R Input to change operator place to Remote
(pulse input)
BBxx-S_S Input to change operator place to Station
(pulse input)
BBxx-L_L Input to change operator place to Local
BBxx-EXCH_IN Input for information exchange with other
BAYCON:s in bays with more than 8 appa-
ratuses
BBxx-RQ_SEL1 Request for selection and reservation of
apparatus 1
BBxx-RQ_SEL2 Request for selection and reservation of
apparatus 2
BBxx-RQ_SEL3 Request for selection and reservation of
apparatus 3
BBxx-RQ_SEL4 Request for selection and reservation of
apparatus 4
BBxx-RQ_SEL5 Request for selection and reservation of
apparatus 5
BBxx-RQ_SEL6 Request for selection and reservation of
apparatus 6
BBxx-RQ_SEL7 Request for selection and reservation of
apparatus 7
BBxx-RQ_SEL8 Request for selection and reservation of
apparatus 8
BBxx-BLK_RE Input for blocking all reservations
BBxx-OVERRIDE Input for overriding the reservation function
including the blocking by BLK_RE
BBxx-RE_B1 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 1
BBxx-RE_B2 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 2
BBxx-RE_B3 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 3
BBxx-RE_B4 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 4
BBxx-RE_B5 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 5
BBxx-RE_B6 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 6
BBxx-RE_B7 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 7
BBxx-RE_B8 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 8
