ABB Network Partner AB
Apparatus control
Version 1.0-00
1MRK 580 150-XEN
Page 6 - 66
BBxx-ACK_F_B Input for acknowledging the reservation of
other bays
BBxx-ANY_ACK Input indicating that at least one acknowl-
edge is still active
BBxx-V_TX Indication for valid transmission of the reser-
vation signals
BBxx-EX_DA_UP Input is 1 if the program that acknowledged
the reservation is running
BBxx-RE_RQ_B Request for reservation from other bays
BBxx-V_RE_RQ Input is 1 for valid request of reservation
from any bay
Table 4: Output signals for BAYCONB
OUT: DESCRIPTION:
BBxx-REMOTE Indication of Remote operator place
BBxx-STATION Indication of Station operator place
BBxx-LOCAL Indication of Local operator place
BBxx-EXCH_OUT Output for information exchange with other
BAYCON:s in bays with more than 8 appa-
ratuses
BBxx-SEL1 Apparatus 1 is selected after reservation
acknowledgement from other bays
BBxx-SEL2 Apparatus 2 is selected after reservation
acknowledgement from other bays
BBxx-SEL3 Apparatus 3 is selected after reservation
acknowledgement from other bays
BBxx-SEL4 Apparatus 4 is selected after reservation
acknowledgement from other bays
BBxx-SEL5 Apparatus 5 is selected after reservation
acknowledgement from other bays
BBxx-SEL6 Apparatus 6 is selected after reservation
acknowledgement from other bays
BBxx-SEL7 Apparatus 7 is selected after reservation
acknowledgement from other bays
BBxx-SEL8 Apparatus 8 is selected after reservation
acknowledgement from other bays
BBxx-RE A reservation has been made in this bay
BBxx-RE_BAYS Request for reservation of other bays
BBxx-ACK_T_B Acknowledgement to other bays that this
bay is reserved
Table 3: Input signals for BAYCONB
IN: DESCRIPTION:
