ABB Network Partner AB
Apparatus control
Version 1.0-00
1MRK 580 150-XEN
Page 6 - 68
7.2.3 BAYCONC
Table 5: Input signals for BAYCONC
IN: DESCRIPTION:
BCxx-S_R Input to change operator place to Remote
(pulse input)
BCxx-S_S Input to change operator place to Station
(pulse input)
BCxx-L_L Input to change operator place to Local
BCxx-RQ_SEL1 Request for selection and reservation of
apparatus 1
BCxx-RQ_SEL2 Request for selection and reservation of
apparatus 2
BCxx-RQ_SEL3 Request for selection and reservation of
apparatus 3
BCxx-RQ_SEL4 Request for selection and reservation of
apparatus 4
BCxx-RQ_SEL5 Request for selection and reservation of
apparatus 5
BCxx-RQ_SEL6 Request for selection and reservation of
apparatus 6
BCxx-RQ_SEL7 Request for selection and reservation of
apparatus 7
BCxx-RQ_SEL8 Request for selection and reservation of
apparatus 8
BCxx-BLK_RE Input for blocking all reservations
BCxx-OVERRIDE Input for overriding the reservation function
including the blocking by BLK_RE
BCxx-RE_B1 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 1
BCxx-RE_B2 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 2
BCxx-RE_B3 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 3
BCxx-RE_B4 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 4
BCxx-RE_B5 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 5
BCxx-RE_B6 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 6
BCxx-RE_B7 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 7
BCxx-RE_B8 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 8
BCxx-ACK_F_B Input for acknowledging the reservation of
other bays
BCxx-ANY_ACK Input indicating that at least one acknowl-
edge is still active
