Apparatus control
ABB Network Partner AB
1MRK 580 150-XEN
Page 6 - 69
Version 1.0-00
BCxx-V_TX Indication for valid transmission of the reser-
vation signals
BCxx-EX_DA_UP Input is 1 if the program that acknowledged
the reservation is running
BCxx-RE_RQ_B Request for reservation from other bays
BCxx-V_RE_RQ Input is 1 for valid request of reservation
from any bay
BCxx-SEL_ACT1 Selection of apparatus 1 is activated by the
program and the selection relay should be
energized
BCxx-SEL_ACT2 Selection of apparatus 2 is activated by the
program and the selection relay should be
energized
BCxx-SEL_ACT3 Selection of apparatus 3 is activated by the
program and the selection relay should be
energized
BCxx-SEL_ACT4 Selection of apparatus 4 is activated by the
program and the selection relay should be
energized
BCxx-SEL_ACT5 Selection of apparatus 5 is activated by the
program and the selection relay should be
energized
BCxx-SEL_ACT6 Selection of apparatus 6 is activated by the
program and the selection relay should be
energized
BCxx-SEL_ACT7 Selection of apparatus 7 is activated by the
program and the selection relay should be
energized
BCxx-SEL_ACT8 Selection of apparatus 8 is activated by the
program and the selection relay should be
energized
BCxx-SEL_CH1 Indication that no selection or execution
relay is energized
BCxx-SEL_CH2 Indication that at least one selection or exe-
cution relay is energized
BCxx-INPBOERR Input for binary input board error
BCxx-OUTBOERR Input for binary output board error
Table 6: Output signals for BAYCONC
OUT: DESCRIPTION:
BCxx-REMOTE Indication of Remote operator place
BCxx-STATION Indication of Station operator place
BCxx-LOCAL Indication of Local operator place
Table 5: Input signals for BAYCONC
IN: DESCRIPTION:
