ABB Network Partner AB
Apparatus control
Version 1.0-00
1MRK 580 150-XEN
Page 6 - 70
BCxx-SEL1 Apparatus 1 is selected after reservation
acknowledgement from other bays
BCxx-SEL2 Apparatus 2 is selected after reservation
acknowledgement from other bays
BCxx-SEL3 Apparatus 3 is selected after reservation
acknowledgement from other bays
BCxx-SEL4 Apparatus 4 is selected after reservation
acknowledgement from other bays
BCxx-SEL5 Apparatus 5 is selected after reservation
acknowledgement from other bays
BCxx-SEL6 Apparatus 6 is selected after reservation
acknowledgement from other bays
BCxx-SEL7 Apparatus 7 is selected after reservation
acknowledgement from other bays
BCxx-SEL8 Apparatus 8 is selected after reservation
acknowledgement from other bays
BCxx-RE A reservation has been made in this bay
BCxx-RE_BAYS Request for reservation of other bays
BCxx-ACK_T_B Acknowledgement to other bays that this
bay is reserved
BCxx-FDB_SEL1 Correct selection relay is energized for
apparatus 1
BCxx-FDB_SEL2 Correct selection relay is energized for
apparatus 2
BCxx-FDB_SEL3 Correct selection relay is energized for
apparatus 3
BCxx-FDB_SEL4 Correct selection relay is energized for
apparatus 4
BCxx-FDB_SEL5 Correct selection relay is energized for
apparatus 5
BCxx-FDB_SEL6 Correct selection relay is energized for
apparatus 6
BCxx-FDB_SEL7 Correct selection relay is energized for
apparatus 7
BCxx-FDB_SEL8 Correct selection relay is energized for
apparatus 8
BCxx-BINPERR Indication for binary input board error
BCxx-BOUTERR Indication for binary output board error
BCxx-AU_OP_V1 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 1
BCxx-AU_OP_V2 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 2
Table 6: Output signals for BAYCONC
OUT: DESCRIPTION:
