Apparatus control
ABB Network Partner AB
1MRK 580 150-XEN
Page 6 - 71
Version 1.0-00
7.2.4 BAYCOND
BCxx-AU_OP_V3 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 3
BCxx-AU_OP_V4 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 4
BCxx-AU_OP_V5 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 5
BCxx-AU_OP_V6 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 6
BCxx-AU_OP_V7 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 7
BCxx-AU_OP_V8 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 8
Table 6: Output signals for BAYCONC
OUT: DESCRIPTION:
Table 7: Input signals for BAYCOND
IN: DESCRIPTION:
BDxx-S_R Input to change operator place to Remote
(pulse input)
BDxx-S_S Input to change operator place to Station
(pulse input)
BDxx-L_L Input to change operator place to Local
BDxx-EXCH_IN Input for information exchange with other
BAYCON:s in bays with more than 8 appa-
ratuses
BDxx-RQ_SEL1 Request for selection and reservation of
apparatus 1
BDxx-RQ_SEL2 Request for selection and reservation of
apparatus 2
BDxx-RQ_SEL3 Request for selection and reservation of
apparatus 3
BDxx-RQ_SEL4 Request for selection and reservation of
apparatus 4
