ABB Network Partner AB
Apparatus control
Version 1.0-00
1MRK 580 150-XEN
Page 6 - 72
BDxx-RQ_SEL5 Request for selection and reservation of
apparatus 5
BDxx-RQ_SEL6 Request for selection and reservation of
apparatus 6
BDxx-RQ_SEL7 Request for selection and reservation of
apparatus 7
BDxx-RQ_SEL8 Request for selection and reservation of
apparatus 8
BDxx-BLK_RE Input for blocking all reservations
BDxx-OVERRIDE Input for overriding the reservation function
including the blocking by BLK_RE
BDxx-RE_B1 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 1
BDxx-RE_B2 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 2
BDxx-RE_B3 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 3
BDxx-RE_B4 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 4
BDxx-RE_B5 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 5
BDxx-RE_B6 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 6
BDxx-RE_B7 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 7
BDxx-RE_B8 Reservation of the own bay only (i.e. not
other bays) at selection from apparatus 8
BDxx-ACK_F_B Input for acknowledging the reservation of
other bays
BDxx-ANY_ACK Input indicating that at least one acknowl-
edge is still active
BDxx-V_TX Indication for valid transmission of the reser-
vation signals
BDxx-EX_DA_UP Input is 1 if the program that acknowledged
the reservation is running
BDxx-RE_RQ_B Request for reservation from other bays
BDxx-V_RE_RQ Input is 1 for valid request of reservation
from any bay
BDxx-SEL_ACT1 Selection of apparatus 1 is activated by the
program and the selection relay should be
energized
BDxx-SEL_ACT2 Selection of apparatus 2 is activated by the
program and the selection relay should be
energized
Table 7: Input signals for BAYCOND
IN: DESCRIPTION:
