Apparatus control
ABB Network Partner AB
1MRK 580 150-XEN
Page 6 - 85
Version 1.0-00
7.2.7 COMCON
Table 13: Input signals for COMCON
IN: DESCRIPTION:
COxx-SEL_RES Input for reset of selection after operation
COxx-SELECT Input stating that a correct selection and
reservation is made in the bay
COxx-R_SEL_O Selection for opening the apparatus from
Remote (pulse input)
COxx-R_SEL_C Selection for closing the apparatus from
Remote (pulse input)
COxx-R_OPEN Execute command for opening the appara-
tus from Remote (pulse input)
COxx-R_CLOSE Execute command for closing the apparatus
from Remote (pulse input)
COxx-R_CANCEL Input for cancelling an operation from
Remote (pulse input)
COxx-REMOTE Input for indicating Remote as valid operator
place
COxx-S_SEL_O Selection for opening the apparatus from
Station (pulse input)
COxx-S_SEL_C Selection for closing the apparatus from
Station (pulse input)
COxx-S_OPEN Execute command for opening the appara-
tus from Station (pulse input)
COxx-S_CLOSE Execute command for closing the apparatus
from Station (pulse input)
COxx-S_CANCEL Input for cancelling an operation from Sta-
tion (pulse input)
COxx-S_BLK_OP Input for blocking operation from Station
(pulse input)
COxx-S_DBL_OP Input for deblocking operation from Station
(pulse input)
COxx-S_IR_OVR Input for overriding selection and reserva-
tion from Station (pulse input)
COxx-S_BL_UPD Input for blocking process updating from
Station (pulse input)
COxx-S_PR_UPD Input for resuming process updating from
Station (pulse input)
COxx-S_MA_U_O Input for manual entry of open position from
Station (pulse input)
COxx-S_MA_U_C Input for manual entry of close position from
Station (pulse input)
COxx-STATION Input for indicating Station as valid operator
place
COxx-L_SEL_O Selection for opening the apparatus from
Local
