ABB Network Partner AB
Apparatus control
Version 1.0-00
1MRK 580 150-XEN
Page 6 - 86
COxx-L_SEL_C Selection for closing the apparatus from
Local
COxx-L_OPEN Execute command for opening the appara-
tus from Local
COxx-L_CLOSE Execute command for closing the apparatus
from Local
COxx-L_IR_OVR Input for overriding selection and reserva-
tion from Local
COxx-LOCAL Input for indicating Local as valid operator
place
COxx-AU_SEL_O Selection for opening the apparatus from an
automatic function (pulse input)
COxx-AU_SEL_C Selection for closing the apparatus from an
automatic function (pulse input)
COxx-AU_OPEN Execute command for opening the appara-
tus from an automatic function (pulse input)
COxx-AU_CLOSE Execute command for closing the apparatus
from an automatic function (pulse input)
COxx-AU_CANC Input for cancelling an operation from an
automatic function (pulse input)
COxx-SEL_SEQ A sequence program is performing an oper-
ation
Table 14: Output signals for COMCON
OUT: DESCRIPTION:
COxx-RQ_SEL Request selection output
COxx-OPEN Open direction output
COxx-CLOSE Close direction output
COxx-EXECUTE Output signal to execute the operation
COxx-CANCEL Output signal to cancel any operation
before an execute command
COxx-OVERRIDE Output signal to override an interlocking and
reservation
COxx-LO_OP_T Indication of a long operation time
COxx-RES_ERR Indication of a failure in the reservation
COxx-R_OP MMI indication stating that Remote is valid
operator place
COxx-S_OP MMI indication stating that Station is valid
operator place
COxx-BLK_OP Output signal for blocking the operation
(pulse output)
Table 13: Input signals for COMCON
IN: DESCRIPTION:
