Apparatus control
ABB Network Partner AB
1MRK 580 150-XEN
Page 6 - 87
Version 1.0-00
COxx-DBL_OP Output signal for deblocking the operation
(pulse output)
COxx-L_OP MMI indication stating that Local is valid
operator place
COxx-BLK_UPD Output signal for blocking the process
updating (pulse output)
COxx-PROC_UPD Output signal for resuming the process
updating (pulse output)
COxx-MA_UPD_O Output signal for manual setting of open
position, when the updating is blocked
(pulse output)
COxx-MA_UPD_C Output signal for manual setting of close
position, when the updating is blocked
(pulse output)
COxx-AU_MODE MMI indication that an automatic function is
performing an operation i.e. input
AU_SEL_O/C is set
COxx-SEQ_STA Indicate that the apparatus is reserved by
the input SEL_SEQ and is not in Local
position
Table 14: Output signals for COMCON
OUT: DESCRIPTION:
