7.2.8 SWICONA
Table 15: Input signals for SWICONA
IN: DESCRIPTION:
SAxx-POSIND_V Input for external position check function,
i.e. valid position of the apparatus
SAxx-POS_L1_O Input for open position indication in phase
L1
SAxx-POS_L2_O Input for open position indication in phase
L2
SAxx-POS_L3_O Input for open position indication in phase
L3
SAxx-POS_L1_C Input for close position indication in phase
L1
SAxx-POS_L2_C Input for close position indication in phase
L2
SAxx-POS_L3_C Input for close position indication in phase
L3
SAxx-BLK_UPD Blocking of updating of the position indica-
tion (pulse input from COMCON)
SAxx-PROC_UPD Resuming of updating of the position indica-
tion (pulse input from COMCON)
SAxx-MA_UPD_O Input for manual setting of open position
(pulse input from COMCON)
SAxx-MA_UPD_C Input for manual setting of close position
(pulse input from COMCON)
SAxx-UPD_BLK Input for blocking of updating (from BLK-
CONK at blocking of all apparatuses in a
bay)
SAxx-SELECT Selection input (from BAYCON, signal
SELx)
SAxx-FDB_SEL Feedback selection input
SAxx-OPEN Open direction for operation (pulse input
from COMCON)
SAxx-CLOSE Close direction for operation (pulse input
from COMCON)
SAxx-AU_OP_V Automatic operation permitted (signal from
BAYCON)
SAxx-EXECUTE Execution of operation (pulse input from
COMCON)
SAxx-CANCEL Cancelling of the selected operation (pulse
input from COMCON)
SAxx-BLK_OPEN Blocking input for open direction
SAxx-BLK_CLOS Blocking input for close direction
SAxx-INT_LOCK Operation blocked by conditions from the
interlocking module
SAxx-SY_RUN To be set to true when the synchro-check is
running
