Apparatus control
ABB Network Partner AB
1MRK 580 150-XEN
Page 6 - 91
Version 1.0-00
7.2.9 SWICONB
Table 17: Input signals for SWICONB
IN: DESCRIPTION:
SBxx-POSIND_V Input for external position check function,
i.e. valid position of the apparatus
SBxx-POS_L1_O Input for open position indication in phase
L1
SBxx-POS_L2_O Input for open position indication in phase
L2
SBxx-POS_L3_O Input for open position indication in phase
L3
SBxx-POS_L1_C Input for close position indication in phase
L1
SBxx-POS_L2_C Input for close position indication in phase
L2
SBxx-POS_L3_C Input for close position indication in phase
L3
SBxx-BLK_UPD Blocking of updating of the position indica-
tion (pulse input from COMCON)
SBxx-PROC_UPD Resuming of updating of the position indica-
tion (pulse input from COMCON)
SBxx-MA_UPD_O Input for manual setting of open position
(pulse input from COMCON)
SBxx-MA_UPD_C Input for manual setting of close position
(pulse input from COMCON)
SBxx-UPD_BLK Input for blocking of updating (from BLK-
CONK at blocking of all apparatuses in a
bay)
SBxx-SELECT Selection input (from BAYCON, signal
SELx)
SBxx-FDB_SEL Feedback selection input
SBxx-OPEN Open direction for operation (pulse input
from COMCON)
SBxx-CLOSE Close direction for operation (pulse input
from COMCON)
SBxx-AU_OP_V Automatic operation permitted (signal from
BAYCON)
SBxx-EXECUTE Execution of operation (pulse input from
COMCON)
SBxx-CANCEL Cancelling of the selected operation (pulse
input from COMCON)
SBxx-BLK_OPEN Blocking input for open direction
SBxx-BLK_CLOS Blocking input for close direction
SBxx-INT_LOCK Operation blocked by conditions from the
interlocking module
