SBxx-SY_RUN Connected to the synchro-check module
(equipment). At true all timers in SWICONB
are stopped
SBxx-SY_FAIL To be set to true when the synchro-check
fails and the command execution will stop
SBxx-AR_SEL Selection input for fast autoreclosing. It is
used only with external selection relays
Table 18: Output signals for SWICONB
OUT: DESCRIPTION:
SBxx-OX Indication that the apparatus is in open posi-
tion. Result of the three single phase indica-
tions or blocking of the process updating or
by the manually entered open position
SBxx-CX Indication that the apparatus is in close
position. Result of the three single phase
indications or blocking of the process updat-
ing or by the manually entered close posi-
tion
SBxx-POS_ERR Position error. Result of that at least one of
following conditions are fulfilled: One phase
is both open and closed, one phase is in
middle position longer than T_POSERR, the
input POSIND_V is false
SBxx-POL_DISC Output indicating pole discordance, after
that the time T_POL has elapsed
SBxx-MA_UPD_P Output indicating manual control of position
updating
SBxx-SEL_OPEN Selection output for open direction
SBxx-SEL_CLOS Selection output for close direction
SBxx-EXE_OPEN Execute output for open direction (settable
pulse length)
SBxx-EXE_CLOS Execute output for close direction (settable
pulse length)
SBxx-SEL_RES Reset the selection after successful or failed
operation (pulse output)
SBxx-SEL_ERR Output indicating a failure in the selection, if
no feedback select signal FDB_SEL is acti-
vated before the time T_SEL has elapsed
SBxx-CMD_ERR Output indicating a command error. That is
done if the position indication of the exe-
cuted apparatus does not indicate a start in
the position change before the time
T_START has elapsed
Table 17: Input signals for SWICONB
IN: DESCRIPTION:
