ABB Network Partner AB
Apparatus control
Version 1.0-00
1MRK 580 150-XEN
Page 6 - 94
7.2.10SWICONC
Table 19: Input signals for SWICONC
IN: DESCRIPTION:
SCxx-POSIND_V Input for external position check function,
i.e. valid position of the apparatus
SCxx-POS_O Input for open position indication
SCxx-POS_C Input for close position indication
SCxx-BLK_UPD Blocking of updating of the position indica-
tion (pulse input from COMCON)
SCxx-PROC_UPD Resuming of updating of the position indica-
tion (pulse input from COMCON)
SCxx-MA_UPD_O Input for manual setting of open position
(pulse input from COMCON)
SCxx-MA_UPD_C Input for manual setting of close position
(pulse input from COMCON)
SCxx-UPD_BLK Input for blocking of updating (from BLK-
CONK at blocking of all apparatuses in a
bay)
SCxx-SELECT Selection input (from BAYCON, signal
SELx)
SCxx-FDB_SEL Feedback selection input
SCxx-OPEN Open direction for operation (pulse input
from COMCON)
SCxx-CLOSE Close direction for operation (pulse input
from COMCON)
SCxx-EXECUTE Execution of operation (pulse input from
COMCON)
SCxx-CANCEL Cancelling of the selected operation (pulse
input from COMCON)
SCxx-BLK_OPEN Blocking input for open direction
SCxx-BLK_CLOS Blocking input for close direction
SCxx-INT_LOCK Operation blocked by conditions from the
interlocking module
SCxx-AU_OP_V Automatic operation permitted (signal from
BAYCON)
Table 20: Output signals for SWICONC
OUT: DESCRIPTION:
SCxx-OX Indication that the apparatus is in open posi-
tion. Result of the input indication or block-
ing of the process updating or by the
manually entered open position
