ABB Network Partner AB
Interlocking
Version 1.0-00
1MRK 580 151-XEN
Page 6 - 194
6.2.3 AB_TRAFO
Table 5: Input signals for AB_TRAFO
IN: DESCRIPTION:
IExx-Q0_OP Signal is 1 if Q0 is open
IExx-Q0_CL Signal is 1 if Q0 is closed
IExx-Q1_OP Signal is 1 if Q1 is open
IExx-Q1_CL Signal is 1 if Q1 is closed
IExx-Q2_OP Signal is 1 if Q2 is open
IExx-Q2_CL Signal is 1 if Q2 is closed
IExx-Q51_OP Signal is 1 if Q51 is open
IExx-Q51_CL Signal is 1 if Q51 is closed
IExx-Q52_OP Signal is 1 if Q52 is open
IExx-Q52_CL Signal is 1 if Q52 is closed
IExx-TQ1_OP Signal is 1 if TQ1 is open
IExx-TQ1_CL Signal is 1 if TQ1 is closed
IExx-TQ2_OP Signal is 1 if TQ2 is open
IExx-TQ2_CL Signal is 1 if TQ2 is closed
IExx-TQ51_OP Signal is 1 if TQ51 is open
IExx-TQ51_CL Signal is 1 if TQ51 is closed
IExx-Q15_OP Signal is 1 if Q15 on busbar A is open
IExx-Q15_CL Signal is 1 if Q0 on busbar A is closed
IExx-Q25_OP Signal is 1 if Q0 on busbar B is open
IExx-Q25_CL Signal is 1 if Q0 on busbar B is closed
IExx-BC_AB_CL There exists a bus coupler connection
between busbar A and B
IExx-VP_BC_AB Switch status of the bus coupler appara-
tuses are valid (open or closed)
IExx-EXDUP_ES Signal is 1 if there is no transmission error
from any bay containing earthing switches
Q15 or Q25
IExx-EXVVA_ES Signal is 1 if the interlocking programs in all
bays containing earthing switches Q15 or
Q25 are running
IExx-EXDUP_BC Signal is 1 if there is no transmission error
from any bus coupler bay
IExx-EXVVA_BC Signal is 1 if the interlocking programs in all
bus coupler bays are running
IExx-Q0EX1 Input for an external condition for apparatus
Q0
IExx-Q0EX2 Input for an external condition for apparatus
Q0
IExx-Q0EX3 Input for an external condition for apparatus
Q0
IExx-Q1EX1 Input for an external condition for apparatus
Q1
