Interlocking
ABB Network Partner AB
1MRK 580 151-XEN
Page 6 - 195
Version 1.0-00
IExx-Q1EX2 Input for an external condition for apparatus
Q1
IExx-Q1EX3 Input for an external condition for apparatus
Q1
IExx-Q2EX1 Input for an external condition for apparatus
Q2
IExx-Q2EX2 Input for an external condition for apparatus
Q2
IExx-Q2EX3 Input for an external condition for apparatus
Q2
Table 6: Output signals for AB_TRAFO
OUT: DESCRIPTION:
IExx-Q0CLREL Closing of Q0 is allowed
IExx-Q0CLITL Closing of Q0 is forbidden
IExx-Q1REL Switching of Q1 is allowed
IExx-Q1ITL Switching of Q1 is forbidden
IExx-Q2REL Switching of Q2 is allowed
IExx-Q2ITL Switching of Q2 is forbidden
IExx-Q51REL Switching of Q51 is allowed
IExx-Q51ITL Switching of Q51 is forbidden
IExx-Q52REL Switching of Q52 is allowed
IExx-Q52ITL Switching of Q52 is forbidden
IExx-Q1OPTR Signal is 1 if Q1 is open
IExx-Q1CLTR Signal is 1 if Q1 is closed
IExx-Q2OPTR Signal is 1 if Q2 is open
IExx-Q2CLTR Signal is 1 if Q2 is closed
IExx-Q1Q2OPTR Signal is 1 if Q1 or Q2 or both are open
IExx-Q1Q2CLTR Signal is 1 if Q1 and Q2 are closed
IExx-VPQ1TR Switch status of Q1 is valid (open or closed)
IExx-VPQ2TR Switch status of Q2 is valid (open or closed)
IExx-VPQ1Q2TR Switch status of Q1 and Q2 are valid (open
or closed)
Table 5: Input signals for AB_TRAFO
IN: DESCRIPTION:
