ABB Network Partner AB
Interlocking
Version 1.0-00
1MRK 580 151-XEN
Page 6 - 196
6.2.4 A1A2_BS
Table 7: Input signals for A1A2_BS
IN: DESCRIPTION:
IHxx-Q0_OP Signal is 1 if Q0 is open
IHxx-Q0_CL Signal is 1 if Q0 is closed
IHxx-Q11_OP Signal is 1 if Q11 is open
IHxx-Q11_CL Signal is 1 if Q11 is closed
IHxx-Q12_OP Signal is 1 if Q12 is open
IHxx-Q12_CL Signal is 1 if Q12 is closed
IHxx-Q51_OP Signal is 1 if Q51 is open
IHxx-Q51_CL Signal is 1 if Q51 is closed
IHxx-Q52_OP Signal is 1 if Q52 is open
IHxx-Q52_CL Signal is 1 if Q52 is closed
IHxx-A1Q15_OP Signal is 1 if Q15 on busbar A1 is open
IHxx-A1Q15_CL Signal is 1 if Q15 on busbar A1 is closed
IHxx-A2Q15_OP Signal is 1 if Q15 on busbar A2 is open
IHxx-A2Q15_CL Signal is 1 if Q15 on busbar A2 is closed
IHxx-BBTR_OP Signal is 1 if no busbar transfer is in
progress concerning this bus section
IHxx-VP_BBTR Switch status are valid for all apparatuses
involved in the busbar transfer
IHxx-EXDUP_AB Signal is 1 if there is no transmission error
from any bay connected to the AB busbars
IHxx-EXVVA_AB Signal is 1 if the interlocking programs in all
bays connected to the AB busbars are run-
ning
IHxx-EXDUP_ES Signal is 1 if there is no transmission error
from any bay containing earthing switches
Q15 in section A1 and A2
IHxx-EXVVA_ES Signal is 1 if the interlocking programs in all
bays containing earthing switches Q15 in
section A1 and A2 are running
IHxx-Q0_O_EX1 Input for an external open condition for
apparatus Q0
IHxx-Q0_O_EX2 Input for an external open condition for
apparatus Q0
IHxx-Q0_O_EX3 Input for an external open condition for
apparatus Q0
IHxx-Q11EX1 Input for an external condition for apparatus
Q11
IHxx-Q11EX2 Input for an external condition for apparatus
Q11
IHxx-Q12EX1 Input for an external condition for apparatus
Q12
IHxx-Q12EX2 Input for an external condition for apparatus
Q12
