Interlocking
ABB Network Partner AB
1MRK 580 151-XEN
Page 6 - 197
Version 1.0-00
Table 8: Output signals for A1A2_BS
OUT: DESCRIPTION:
IHxx-Q0OPREL Opening of Q0 is allowed
IHxx-Q0OPITL Opening of Q0 is forbidden
IHxx-Q0CLREL Closing of Q0 is allowed
IHxx-Q0CLITL Closing of Q0 is forbidden
IHxx-Q11REL Switching of Q11 is allowed
IHxx-Q11ITL Switching of Q11 is forbidden
IHxx-Q12REL Switching of Q12 is allowed
IHxx-Q12ITL Switching of Q12 is forbidden
IHxx-Q51REL Switching of Q51 is allowed
IHxx-Q51ITL Switching of Q51 is forbidden
IHxx-Q52REL Switching of Q52 is allowed
IHxx-Q52ITL Switching of Q52 is forbidden
IHxx-A1A2OPTR No bus coupler connection between bus
section A1 and A2
IHxx-A1A2CLTR Bus coupler connection between bus sec-
tion A1 and A2
IHxx-Q11OPTR Signal is 1 if Q11 is open
IHxx-Q11CLTR Signal is 1 if Q11 is closed
IHxx-Q12OPTR Signal is 1 if Q12 is open
IHxx-Q12CLTR Signal is 1 if Q12 is closed
IHxx-VPA1A2TR Switch status of Q0, Q11 and Q12 are valid
(open or closed)
IHxx-VPQ11TR Switch status of Q11 is valid (open or
closed)
IHxx-VPQ12TR Switch status of Q12 is valid (open or
closed)
