Interlocking
ABB Network Partner AB
1MRK 580 151-XEN
Page 6 - 199
Version 1.0-00
6.2.6 BB_ES
IIxx-Q11CLREL For GIS closing of Q11 is allowed
IIxx-Q11CLITL For GIS closing of Q11 is forbidden
IIxx-DCOPTR Signal is 1 if the bus section disconnector is
open
IIxx-DCCLTR Signal is 1 if the bus section disconnector is
closed
IIxx-VPDCTR Switch status of Q11 is valid (open or
closed)
Table 10: Output signals for A1A2_DC
OUT: DESCRIPTION:
Table 11: Input signals for BB_ES
IN: DESCRIPTION:
IJxx-Q15_OP Signal is 1 if Q15 on this busbar part is open
IJxx-Q15_CL Signal is 1 if Q15 on this busbar part is
closed
IJxx-ABCDC_OP Signal is 1 if all disconnectors on this busbar
part are open
IJxx-VP_ABCDC The switch status of all disconnectors on
this busbar part are valid.
IJxx-EXDUP_BB Signal is 1 if no transmission error from any
bay containing all disconnectors on this bus-
bar part
IJxx-EXVVA_BB Signal is 1 if the interlocking programs in all
bays containing all disconnectors on this
busbar part are running
Table 12: Output signals for BB_ES
OUT: DESCRIPTION:
IJxx-Q15REL Switching of Q15 is allowed
IJxx-Q15ITL Switching of Q15 is forbidden
IJxx-BBESOPTR Signal is 1 if Q15 on this busbar part is open
IJxx-BBESCLTR Signal is 1 if Q15 on this busbar part is
closed
