ABB Network Partner AB
Interlocking
Version 1.0-00
1MRK 580 151-XEN
Page 6 - 200
6.2.7 DB_BUS_A
Table 13: Input signals for DB_BUS_A
IN: DESCRIPTION:
IBxx-Q01_OP Signal is 1 if Q01 is open
IBxx-Q01_CL Signal is 1 if Q01 is closed
IBxx-Q1_OP Signal is 1 if Q1 is open
IBxx-Q1_CL Signal is 1 if Q1 is closed
IBxx-Q61_OP Signal is 1 if Q61 is open
IBxx-Q61_CL Signal is 1 if Q61 is closed
IBxx-Q51_OP Signal is 1 if Q51 is open
IBxx-Q51_CL Signal is 1 if Q51 is closed
IBxx-Q52_OP Signal is 1 if Q52 is open
IBxx-Q52_CL Signal is 1 if Q52 is closed
IBxx-Q53_OP Signal is 1 if Q53 is open
IBxx-Q53_CL Signal is 1 if Q53 is closed
IBxx-Q15_OP Signal is 1 if Q15 on busbar A is open
IBxx-Q15_CL Signal is 1 if Q15 on busbar A is closed
IBxx-EXDUP_ES Signal is 1 if there is no transmission error
from any bay containing earthing switches
Q15
IBxx-EXVVA_ES Signal is 1 if the interlocking programs in all
bays containing earthing switches Q15 are
running
IBxx-Q61EX1 Input for an external condition for apparatus
Q61
IBxx-Q61EX2 Input for an external condition for apparatus
Q61
IBxx-Q1EX1 Input for an external condition for apparatus
Q1
IBxx-Q1EX2 Input for an external condition for apparatus
Q1
Table 14: Output signals for DB_BUS_A
OUT: DESCRIPTION:
IBxx-Q01CLREL Closing of Q01 is allowed
IBxx-Q01CLITL Closing of Q01 is forbidden
IBxx-Q61REL Switching of Q61 is allowed
IBxx-Q61ITL Switching of Q61 is forbidden
IBxx-Q1REL Switching of Q1 is allowed
IBxx-Q1ITL Switching of Q1 is forbidden
IBxx-Q51REL Switching of Q51 is allowed
IBxx-Q51ITL Switching of Q51 is forbidden
IBxx-Q52REL Switching of Q52 is allowed
