Interlocking
ABB Network Partner AB
1MRK 580 151-XEN
Page 6 - 201
Version 1.0-00
6.2.8 DB_LINE
IBxx-Q52ITL Switching of Q52 is forbidden
IBxx-Q1OPTR Signal is 1 if Q1 is open
IBxx-Q1CLTR Signal is 1 if Q1 is closed
IBxx-VPQ1TR Switch status of Q1 is valid (open or closed)
Table 14: Output signals for DB_BUS_A
OUT: DESCRIPTION:
Table 15: Input signals for DB_LINE
IN: DESCRIPTION:
IAxx-Q01_OP Signal is 1 if Q01 is open
IAxx-Q01_CL Signal is 1 if Q01 is closed
IAxx-Q02_OP Signal is 1 if Q02 is open
IAxx-Q02_CL Signal is 1 if Q02 is closed
IAxx-Q61_OP Signal is 1 if Q61 is open
IAxx-Q61_CL Signal is 1 if Q61 is closed
IAxx-Q51_OP Signal is 1 if Q51 is open
IAxx-Q51_CL Signal is 1 if Q51 is closed
IAxx-Q52_OP Signal is 1 if Q52 is open
IAxx-Q52_CL Signal is 1 if Q52 is closed
IAxx-Q62_OP Signal is 1 if Q62 is open
IAxx-Q62_CL Signal is 1 if Q62 is closed
IAxx-Q54_OP Signal is 1 if Q54 is open
IAxx-Q54_CL Signal is 1 if Q54 is closed
IAxx-Q55_OP Signal is 1 if Q55 is open
IAxx-Q55_CL Signal is 1 if Q55 is closed
IAxx-Q9_OP Signal is 1 if Q9 is open
IAxx-Q9_CL Signal is 1 if Q9 is closed
IAxx-Q53_OP Signal is 1 if Q53 is open
IAxx-Q53_CL Signal is 1 if Q53 is closed
IAxx-Q8_OP Signal is 1 if Q8 is open
IAxx-Q8_CL Signal is 1 if Q8 is closed
IAxx-VOLT_OP There is no voltage on the line and no fuse
failure
IAxx-VOLT_CL There is voltage on the line and or a VT
(fuse) failure
IAxx-Q9EX1 Input for an external condition for apparatus
Q9
IAxx-Q9EX2 Input for an external condition for apparatus
Q9
IAxx-Q9EX3 Input for an external condition for apparatus
Q9
