ABB Network Partner AB
Interlocking
Version 1.0-00
1MRK 580 151-XEN
Page 6 - 202
6.2.9 DB_BUS_B
IAxx-Q9EX4 Input for an external condition for apparatus
Q9
IAxx-Q9EX5 Input for an external condition for apparatus
Q9
Table 16: Output signals for DB_LINE
OUT: DESCRIPTION:
IAxx-Q9REL Switching of Q9 is allowed
IAxx-Q9ITL Switching of Q9 is forbidden
IAxx-Q53REL Switching of Q53 is allowed
IAxx-Q53ITL Switching of Q53 is forbidden
IAxx-Q8REL Switching of Q8 is allowed
IAxx-Q8ITL Switching of Q8 is forbidden
Table 15: Input signals for DB_LINE
IN: DESCRIPTION:
Table 17: Input signals for DB_BUS_B
IN: DESCRIPTION:
ICxx-Q02_OP Signal is 1 if Q02 is open
ICxx-Q02_CL Signal is 1 if Q02 is closed
ICxx-Q62_OP Signal is 1 if Q62 is open
ICxx-Q62_CL Signal is 1 if Q62 is closed
ICxx-Q2_OP Signal is 1 if Q2 is open
ICxx-Q2_CL Signal is 1 if Q2 is closed
ICxx-Q54_OP Signal is 1 if Q54 is open
ICxx-Q54_CL Signal is 1 if Q54 is closed
ICxx-Q55_OP Signal is 1 if Q55 is open
ICxx-Q55_CL Signal is 1 if Q55 is closed
ICxx-Q53_OP Signal is 1 if Q53 is open
ICxx-Q53_CL Signal is 1 if Q53 is closed
ICxx-Q25_OP Signal is 1 if Q25 on busbar B is open
ICxx-Q25_CL Signal is 1 if Q25 on busbar B is closed
ICxx-EXDUP_ES Signal is 1 if there is no transmission error
from any bay containing earthing switches
Q25
ICxx-EXVVA_ES Signal is 1 if the interlocking programs in all
bays containing earthing switches Q25 are
running
ICxx-Q62EX1 Input for an external condition for apparatus
Q62
