Interlocking
ABB Network Partner AB
1MRK 580 151-XEN
Page 6 - 203
Version 1.0-00
ICxx-Q62EX2 Input for an external condition for apparatus
Q62
ICxx-Q2EX1 Input for an external condition for apparatus
Q2
ICxx-Q2EX2 Input for an external condition for apparatus
Q2
Table 18: Output signals for DB_BUS_B
OUT: DESCRIPTION:
ICxx-Q02CLREL Closing of Q02 is allowed
ICxx-Q02CLITL Closing of Q02 is forbidden
ICxx-Q62REL Switching of Q62 is allowed
ICxx-Q62ITL Switching of Q62 is forbidden
ICxx-Q2REL Switching of Q2 is allowed
ICxx-Q2ITL Switching of Q2 is forbidden
ICxx-Q54REL Switching of Q54 is allowed
ICxx-Q54ITL Switching of Q54 is forbidden
ICxx-Q55REL Switching of Q55 is allowed
ICxx-Q55ITL Switching of Q55 is forbidden
ICxx-Q2OPTR Signal is 1 if Q2 is open
ICxx-Q2CLTR Signal is 1 if Q2 is closed
ICxx-VPQ2TR Switch status of Q2 is valid (open or closed)
