ABB Network Partner AB
Interlocking
Version 1.0-00
1MRK 580 151-XEN
Page 6 - 204
6.2.10BH_LINE_A
Table 19: Input signals for BH_LINE_A
IN: DESCRIPTION:
ILxx-Q0_OP Signal is 1 if Q0 is open
ILxx-Q0_CL Signal is 1 if Q0 is closed
ILxx-Q6_OP Signal is 1 if Q6 is open
ILxx-Q6_CL Signal is 1 if Q6 is closed
ILxx-Q1_OP Signal is 1 if Q1 is open
ILxx-Q1_CL Signal is 1 if Q1 is closed
ILxx-Q51_OP Signal is 1 if Q51 is open
ILxx-Q51_CL Signal is 1 if Q51 is closed
ILxx-Q52_OP Signal is 1 if Q52 is open
ILxx-Q52_CL Signal is 1 if Q52 is closed
ILxx-Q53_OP Signal is 1 if Q53 is open
ILxx-Q53_CL Signal is 1 if Q53 is closed
ILxx-Q9_OP Signal is 1 if Q9 is open
ILxx-Q9_CL Signal is 1 if Q9 is closed
ILxx-Q8_OP Signal is 1 if Q8 is open
ILxx-Q8_CL Signal is 1 if Q8 is closed
ILxx-CQ0_OP Signal is 1 if Q0 in module BH_CONN is
open
ILxx-CQ0_CL Signal is 1 if Q0 in module BH_CONN is
closed
ILxx-CQ61_OP Signal is 1 if Q61 in module BH_CONN is
open
ILxx-CQ61_CL Signal is 1 if Q61 in module BH_CONN is
closed
ILxx-CQ51_OP Signal is 1 if Q51 in module BH_CONN is
open
ILxx-CQ51_CL Signal is 1 if Q51 in module BH_CONN is
closed
ILxx-CQ52_OP Signal is 1 if Q52 in module BH_CONN is
open
ILxx-CQ52_CL Signal is 1 if Q52 in module BH_CONN is
closed
ILxx-Q15_OP Signal is 1 if Q15 on busbar A is open
ILxx-Q15_CL Signal is 1 if Q15 on busbar A is closed
ILxx-VOLT_OP There is no voltage on the line and not fuse
failure
ILxx-VOLT_CL There is voltage on the line or there is a VT
(fuse) failure
ILxx-EXDUP_ES Signal is 1 if there is no transmission error
from any bay containing earthing switches
Q15
ILxx-EXVVA_ES Signal is 1 if the interlocking programs in all
bays containing earthing switches Q15
