Interlocking
ABB Network Partner AB
1MRK 580 151-XEN
Page 6 - 205
Version 1.0-00
ILxx-Q6EX1 Input for an external condition for apparatus
Q6
ILxx-Q6EX2 Input for an external condition for apparatus
Q6
ILxx-Q1EX1 Input for an external condition for apparatus
Q1
ILxx-Q1EX2 Input for an external condition for apparatus
Q1
ILxx-Q9EX1 Input for an external condition for apparatus
Q9
ILxx-Q9EX2 Input for an external condition for apparatus
Q9
ILxx-Q9EX3 Input for an external condition for apparatus
Q9
ILxx-Q9EX4 Input for an external condition for apparatus
Q9
ILxx-Q9EX5 Input for an external condition for apparatus
Q9
ILxx-Q9EX6 Input for an external condition for apparatus
Q9
ILxx-Q9EX7 Input for an external condition for apparatus
Q9
Table 20: Output signals for BH_LINE_A
OUT: DESCRIPTION:
ILxx-Q0CLREL Closing of Q0 is allowed
ILxx-Q0CLITL Closing of Q0 is forbidden
ILxx-Q6REL Switching of Q6 is allowed
ILxx-Q6ITL Switching of Q6 is forbidden
ILxx-Q1REL Switching of Q1 is allowed
ILxx-Q1ITL Switching of Q1 is forbidden
ILxx-Q51REL Switching of Q51 is allowed
ILxx-Q51ITL Switching of Q51 is forbidden
ILxx-Q52REL Switching of Q52 is allowed
ILxx-Q52ITL Switching of Q52 is forbidden
ILxx-Q53REL Switching of Q53 is allowed
ILxx-Q53ITL Switching of Q53 is forbidden
ILxx-Q9REL Switching of Q9 is allowed
ILxx-Q9ITL Switching of Q9 is forbidden
ILxx-Q8REL Switching of Q8 is allowed
ILxx-Q8ITL Switching of Q8 is forbidden
Table 19: Input signals for BH_LINE_A
IN: DESCRIPTION:
