ABB Network Partner AB
Interlocking
Version 1.0-00
1MRK 580 151-XEN
Page 6 - 206
6.2.11BH_CONN
ILxx-Q1OPTR Signal is 1 if Q1 is open
ILxx-Q1CLTR Signal is 1 if Q1 is closed
ILxx-VPQ1TR Switch status of Q1 is valid (open or closed)
Table 20: Output signals for BH_LINE_A
OUT: DESCRIPTION:
Table 21: Input signals for BH_CONN
IN: DESCRIPTION:
IKxx-Q0_OP Signal is 1 if Q0 is open
IKxx-Q0_CL Signal is 1 if Q0 is closed
IKxx-Q61_OP Signal is 1 if Q61 is open
IKxx-Q61_CL Signal is 1 if Q61 is closed
IKxx-Q62_OP Signal is 1 if Q62 is open
IKxx-Q62_CL Signal is 1 if Q62 is closed
IKxx-Q51_OP Signal is 1 if Q51 is open
IKxx-Q51_CL Signal is 1 if Q51 is closed
IKxx-Q52_OP Signal is 1 if Q52 is open
IKxx-Q52_CL Signal is 1 if Q52 is closed
IKxx-1Q53_OP Signal is 1 if Q53 on line 1 is open
IKxx-1Q53_CL Signal is 1 if Q53 on line 1 is closed
IKxx-2Q53_OP Signal is 1 if Q53 on line 2 is open
IKxx-2Q53_CL Signal is 1 if Q53 on line 2 is closed
IKxx-Q61EX1 Input for an external condition for apparatus
Q61
IKxx-Q61EX2 Input for an external condition for apparatus
Q61
IKxx-Q62EX1 Input for an external condition for apparatus
Q62
IKxx-Q62EX2 Input for an external condition for apparatus
Q62
Table 22: Output signals for BH_CONN
OUT: DESCRIPTION:
IKxx-Q0CLREL Closing of Q0 is allowed
IKxx-Q0CLITL Closing of Q0 is forbidden
IKxx-Q61REL Switching of Q61 is allowed
IKxx-Q61ITL Switching of Q61 is forbidden
IKxx-Q62REL Switching of Q62 is allowed
IKxx-Q62ITL Switching of Q62 is forbidden
