Interlocking
ABB Network Partner AB
1MRK 580 151-XEN
Page 6 - 207
Version 1.0-00
6.2.12BH_LINE_B
IKxx-Q51REL Switching of Q51 is allowed
IKxx-Q51ITL Switching of Q51 is forbidden
IKxx-Q52REL Switching of Q52 is allowed
IKxx-Q52ITL Switching of Q52 is forbidden
Table 22: Output signals for BH_CONN
OUT: DESCRIPTION:
Table 23: Input signals for BH_LINE_B
IN: DESCRIPTION:
IMxx-Q0_OP Signal is 1 if Q0 is open
IMxx-Q0_CL Signal is 1 if Q0 is closed
IMxx-Q6_OP Signal is 1 if Q6 is open
IMxx-Q6_CL Signal is 1 if Q6 is closed
IMxx-Q2_OP Signal is 1 if Q2 is open
IMxx-Q2_CL Signal is 1 if Q2 is closed
IMxx-Q51_OP Signal is 1 if Q51 is open
IMxx-Q51_CL Signal is 1 if Q51 is closed
IMxx-Q52_OP Signal is 1 if Q52 is open
IMxx-Q52_CL Signal is 1 if Q52 is closed
IMxx-Q53_OP Signal is 1 if Q53 is open
IMxx-Q53_CL Signal is 1 if Q53 is closed
IMxx-Q9_OP Signal is 1 if Q9 is open
IMxx-Q9_CL Signal is 1 if Q9 is closed
IMxx-Q8_OP Signal is 1 if Q8 is open
IMxx-Q8_CL Signal is 1 if Q8 is closed
IMxx-CQ0_OP Signal is 1 if Q0 in module BH_CONN is
open
IMxx-CQ0_CL Signal is 1 if Q0 in module BH_CONN is
closed
IMxx-CQ62_OP Signal is 1 if Q62 in module BH_CONN is
open
IMxx-CQ62_CL Signal is 1 if Q62 in module BH_CONN is
closed
IMxx-CQ51_OP Signal is 1 if Q51 in module BH_CONN is
open
IMxx-CQ51_CL Signal is 1 if Q51 in module BH_CONN is
closed
IMxx-CQ52_OP Signal is 1 if Q52 in module BH_CONN is
open
IMxx-CQ52_CL Signal is 1 if Q52 in module BH_CONN is
closed
IMxx-Q25_OP Signal is 1 if Q25 on busbar B is open
