Measurement of alternating

quantities

ABB Network Partner AB

1MRK 580 159-XEN

Page 7 - 31

Version 1.0-00

Frequency measuring channel

Operation Off, On Operation of the measuring channel enabled (On) or disabled (Off)

RepInt (0-3600)Seconds Duration of time interval between two reports at periodic reporting

function. Setting to 0 disables the periodic reporting.

EnAlarms Off, On Produces an immediate event at operation of any alarm monitoring ele-

ment, when On

EnAlRem Off, On Produces an immediate event at reset of any alarm monitoring element,

when On.

Hysteres (0.0-99.9)Hz Hysteresis for the set values of the monitoring elements in one measur-

ing channel.

LowAlarm (0.0-99.9)Hz Determines the operating value of the monitoring element which pro-

duces logical signal DA15-LOWALARM

LowWarn (0.0-99.9)Hz Determines the operating value of the monitoring element which pro-

duces logical signal DA15-LOWARN

HiWarn (0.0-99.9)Hz Determines the operating value of the monitoring element which pro-

duces logical signal DA15-HIWARN

HiAlarm (0.0-99.9)Hz Determines the operating value of the monitoring element which pro-

duces logical signal DA15-HIALARM

EnDeadB Off, On Enables (On) or disables (Off) the amplitude dead-band supervision

function

DeadBand (0.0-99.9)Hz Width of the amplitude dead-band within the ADBS function

EnIDeadB Off, On Enables (On) or disables (Off) the integrating dead-band supervision

function.

IDeadB (0.0-99.9)Hz Determines the width of the band within the IDBS function. Be aware of

the sampling frequency

EnDeadBP Off, On Enables (On) or disables (Off) the periodic dead-band reporting

Reporting of events to the station control system (SCS) via LON

port

EventMask f No Events, Report

Events
