Measurement of alternating
quantities
Version 1.0-00
1MRK 580 159-XEN
Page 7 - 32
EventMask I3 No Events, Report
Events
Enables (Report Events) or disables (No Events) reporting of events
from channel DA08 to the SCS
EventMask I2 No Events, Report
Events
Enables (Report Events) or disables (No Events) reporting of events
from channel DA07 to the SCS
EventMask I1 No Events, Report
Events
Enables (Report Events) or disables (No Events) reporting of events
from channel DA06 to the SCS
EventMask U5 No Events, Report
Events
Enables (Report Events) or disables (No Events) reporting of events
from channel DA05 to the SCS
EventMask U4 No Events, Report
Events
Enables (Report Events) or disables (No Events) reporting of events
from channel DA04 to the SCS
EventMask U3 No Events, Report
Events
Enables (Report Events) or disables (No Events) reporting of events
from channel DA03 to the SCS
EventMask U2 No Events, Report
Events
Enables (Report Events) or disables (No Events) reporting of events
from channel DA02 to the SCS
EventMask U1 No Events, Report
Events
Enables (Report Events) or disables (No Events) reporting of events
from channel DA01 to the SCS
The following parameters are settable under the Configuration-
AnalogInputs submenu. Settings are possible also by means of the
MMI module
Name 13 character name Name of the analogue measuring channel.Enter up to 13 characters for
the name of measured quantity. the name appears automatically in dis-
turbance evaluation program REVAL. The default names are:
U1,..,U5,I1,..I5,U,I,P,Q,f
VTPrim (1-9999) kV Rated primary voltage of the voltage instrument transformer connected
to the Un (n = 1 to 5) measuring channel
CTPrim (1-9999) A Rated primary current of the current instrument transformer connected
to the In (n = 1 to 5) measuring channel
PARAMETER: SETTING RANGE: DESCRIPTION:
