GUID-C98D972D-D1D8-4734-B419-161DBC0DC97B V1 EN-US
Figure 27: Function button panel
The indication LED panel shows on request the alarm text labels for the indication
LEDs. Three indication LED pages are available.
GUID-5157100F-E8C0-4FAB-B979-FD4A971475E3 V1 EN-US
Figure 28: Indication LED panel
The function button and indication LED panels are not visible at the same time. Each
panel is shown by pressing one of the function buttons or the Multipage button.
Pressing the ESC button clears the panel from the display. Both panels have a dynamic
width that depends on the label string length.
Section 5 1MRK 511 401-UUS A
Local HMI
94 Bay control REC670 2.2 ANSI
Application manual
