14.9.1 Identification
SEMOD176456-2 v3
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Single point generic control 8 signals SPC8GAPC - -
14.9.2 Application
SEMOD176511-4 v6
The Single point generic control 8 signals (SPC8GAPC) function block is a collection
of 8 single point commands that can be used for direct commands for example reset of
LED's or putting IED in "ChangeLock" state from remote. In this way, simple
commands can be sent directly to the IED outputs, without confirmation. Confirmation
(status) of the result of the commands is supposed to be achieved by other means, such
as binary inputs and SPGAPC function blocks.
PSTO is the universal operator place selector for all control functions.
Even if PSTO can be configured to allow LOCAL or ALL operator
positions, the only functional position usable with the SPC8GAPC
function block is REMOTE.
14.9.3 Setting guidelines
SEMOD176518-4 v6
The parameters for the single point generic control 8 signals (SPC8GAPC) function are
set via the local HMI or PCM600.
Operation: turning the function operation Enabled/Disabled.
There are two settings for every command output (totally 8):
PulseModex: decides if the command signal for output x is Latched (steady) or Pulsed.
tPulsex: if PulseModex is set to Pulsed, then tPulsex will set the length of the pulse (in
seconds).
14.10 AutomationBits, command function for DNP3.0
AUTOBITS
SEMOD158589-1 v3
1MRK 511 401-UUS A Section 14
Control
Bay control REC670 2.2 ANSI 459
Application manual
