2.5 Communication
GUID-5F144B53-B9A7-4173-80CF-CD4C84579CB5 v15
IEC 61850 or function
name
ANSI Function description Bay control
REC670
(Customized)
Station communication
LONSPA, SPA SPA communication protocol 1
ADE LON communication protocol 1
HORZCOMM Network variables via LON 1
RS485GEN RS485 1
DNPGEN DNP3.0 communication general protocol 1
CHSERRS485 DNP3.0 for EIA-485 communication protocol 1
CH1TCP, CH2TCP,
CH3TCP, CH4TCP
DNP3.0 for TCP/IP communication protocol 1
CHSEROPT DNP3.0 for TCP/IP and EIA-485 communication protocol 1
MSTSER DNP3.0 serial master 1
MST1TCP,
MST2TCP,
MST3TCP,
MST4TCP
DNP3.0 for TCP/IP communication protocol 1
DNPFREC DNP3.0 fault records for TCP/IP and EIA-485 communication
protocol
1
IEC 61850-8-1 IEC 61850 1
GOOSEINTLKRCV Horizontal communication via GOOSE for interlocking 59
GOOSEBINRCV GOOSE binary receive 16
GOOSEDPRCV GOOSE function block to receive a double point value 64
GOOSEINTRCV GOOSE function block to receive an integer value 32
GOOSEMVRCV GOOSE function block to receive a measurand value 60
GOOSESPRCV GOOSE function block to receive a single point value 64
GOOSEVCTRRCV Horizontal communication via GOOSE for VCTR 7
GOOSEVCTRCONF GOOSE VCTR configuration for send and receive 1
MULTICMDRCV,
MULTICMDSND
Multiple command and transmit 60/10
OPTICAL103 IEC 60870-5-103 Optical serial communication 1
RS485103 IEC 60870-5-103 serial communication for RS485 1
AGSAL Generic security application component 1
LD0LLN0 IEC 61850 LD0 LLN0 1
SYSLLN0 IEC 61850 SYS LLN0 1
Table continues on next page
Section 2 1MRK 511 401-UUS A
Application
48 Bay control REC670 2.2 ANSI
