ABB rec670 Applications Manual

IEC 61850 or function
name
ANSI Function description Bay control
REC670
(Customized)
LPHD Physical device information 1
PCMACCS IED configuration protocol 1
SECALARM Component for mapping security events on protocols such as
DNP3 and IEC103
1
FSTACCS Field service tool access 1
IEC 61850-9-2 Process bus communication, 8 merging units 0-1
ACTIVLOG Activity logging 1
ALTRK Service tracking 1
PRP IEC 62439-3 Parallel redundancy protocol 0-1
HSR IEC 62439-3 High-availability seamless redundancy 0-1
PMUCONF,
PMUREPORT,
PHASORREPORT1,
ANALOGREPORT1
BINARYREPORT1,
SMAI1 - SMAI12
3PHSUM
PMUSTATUS
Synchrophasor report, 8 phasors (see Table
9) 0-1
PTP Precision time protocol 1
FRONTSTATUS Access point diagnostic for front Ethernet port 1
SCHLCCH Access point diagnostic for non-redundant Ethernet port 6
RCHLCCH Access point diagnostic for redundant Ethernet ports 3
DHCP DHCP configuration for front access point 1
QUALEXP IEC 61850 quality expander 96
Remote communication
BinSignRec1_1
BinSignRec1_2
BinSignReceive2
Binary signal transfer receive 3/3/6
BinSignTrans1_1
BinSignTrans1_2
BinSignTransm2
Binary signal transfer transmit 3/3/6
BinSigRec1_12M
BinSigRec1_22M
BinSigTran1_12M
BinSigTran1_22M
Binary signal transfer, 2Mbit receive/transmit 3
LDCMTRN Transmission of analog data from LDCM 1
LDCMTRN_2M Transmission of analog data from LDCM, 2Mbit 6
LDCMRecBinStat1
LDCMRecBinStat2
LDCMRecBinStat3
Receive binary status from remote LDCM 6/3/3
LDCMRecBinS2_2M Receive binary status from LDCM, 2Mbit 3
Table continues on next page
1MRK 511 401-UUS A Section 2
Application
Bay control REC670 2.2 ANSI 49
Application manual
