IEC 61850 or function

name

ANSI Function description Bay control

REC670

(Customized)

LDCMRecBinS3_2M Receive binary status from remote LDCM, 2Mbit 3

Scheme communication

ZCPSCH 85 Scheme communication logic with delta based blocking scheme

signal transmit

0-1

ZCRWPSCH 85 Current reversal and weak-end infeed logic for distance protection 0-1

ZCLCPSCH Local acceleration logic 0-1

ECPSCH 85 Scheme communication logic for residual overcurrent protection 0-1

ECRWPSCH 85 Current reversal and weak-end infeed logic for residual

overcurrent protection

0-1

Table 9: Number of function instances in Synchrophasor report, 8 phasors

Function name Function description Number of instances

PMUCONF Configuration parameters for C37.118 2011 and IEEE1344 protocol 1

PMUREPORT Protocol reporting via IEEE 1344 and C37.118 1

PHASORREPORT1 Protocol reporting of phasor data via IEEE 1344 and C37.118, phasors 1-8 1

ANALOGREPORT1 Protocol reporting of analog data via IEEE 1344 and C37.118, analogs 1-8 1

BINARYREPORT1 Protocol reporting of binary data via IEEE 1344 and C37.118, binary 1-8 1

SMAI1–SMAI12 Signal matrix for analog inputs 1

3PHSUM Summation block 3 phase 6

PMUSTATUS Diagnostics for C37.118 2011 and IEEE1344 protocol 1

Section 2 1MRK 511 401-UUS A

Application

50 Bay control REC670 2.2 ANSI

Application manual
