Function block name Edition 1 logical nodes Edition 2 logical nodes
NS2PTOC NS2LLN0
NS2PTOC
NS2PTRC
NS2PTOC
NS2PTRC
NS4PTOC EF4LLN0
EF4PTRC
EF4RDIR
GEN4PHAR
PH1PTOC
EF4PTRC
EF4RDIR
PH1PTOC
O2RWPTOV GEN2LLN0
O2RWPTOV
PH1PTRC
O2RWPTOV
PH1PTRC
OC4PTOC OC4LLN0
GEN4PHAR
PH3PTOC
PH3PTRC
GEN4PHAR
PH3PTOC
PH3PTRC
OEXPVPH OEXPVPH OEXPVPH
OOSPPAM OOSPPAM OOSPPAM
OOSPTRC
OV2PTOV GEN2LLN0
OV2PTOV
PH1PTRC
OV2PTOV
PH1PTRC
PAPGAPC PAPGAPC PAPGAPC
PCFCNT PCGGIO PCFCNT
PH4SPTOC GEN4PHAR
OCNDLLN0
PH1BPTOC
PH1PTRC
GEN4PHAR
PH1BPTOC
PH1PTRC
PHPIOC PHPIOC PHPIOC
PSLPSCH ZMRPSL PSLPSCH
PSPPPAM PSPPPAM PSPPPAM
PSPPTRC
QCBAY QCBAY BAY/LLN0
QCRSV QCRSV QCRSV
RCHLCCH RCHLCCH RCHLCCH
REFPDIF REFPDIF REFPDIF
ROTIPHIZ ROTIPHIZ ROTIPHIZ
ROTIPTRC
ROV2PTOV GEN2LLN0
PH1PTRC
ROV2PTOV
PH1PTRC
ROV2PTOV
SAPFRC SAPFRC SAPFRC
SAPTOF SAPTOF SAPTOF
SAPTUF SAPTUF SAPTUF
SCCVPTOC SCCVPTOC SCCVPTOC
Table continues on next page
Section 1 1MRK 511 401-UUS A
Introduction
32 Bay control REC670 2.2 ANSI
