ABB REX610 - Internal Fault Details and Codes

• Range 0...255
Internal Fault
Test
Code 00. 01. 08. 008. 19
20. 01. 2021
22: 20: 34. 690
GUID-3C2CEBF9-8D06-4D1F-AF38-50A7E3E330F9 V1 EN-US
Figure 48: Fault indication
Table 18: Internal fault indications and codes
Fault indication Error category Additional information
File system error 7 A file system error has occurred
Test 8 Internal fault test activated by the user
USB powered 12 Device powered with USB
RAM error
80
1)
Memory error
ROM error 81 Failure in internal NV memory
PSU traceability invalid 160 Invalid PSU card traceability data
DIO traceability invalid 161 Invalid DIO card traceability data
AIU traceability invalid 162 Invalid AIU card traceability data
AIC traceability invalid 163 Invalid AIC card traceability data
HMI traceability invalid 164 Invalid HMI card traceability data
Product traceability invalid 165 Invalid product traceability data
LHMI LCD error 166 Failure in LCD detection
AIU card error 171 Error in the AIU card
DIO card error 172 Error in the DIO card
AIC card error 173 Error in the AIC card
Firmware update error
175
1)
Software update failed
CPU exception
176
1)
CPU exception
HW config mismatch 177 Mismatch between the HW
configuration and the HW cards
connected to the relay
System Boot up failure
179
1)
Error during system bootup
HMI Card error 181 Error in the HMI card
RTC Error 182 Error in the RTC
Device Resource error 183 IRF triggered
One of the mandatory files missing
COM failure
184
1)
COM failure
ADC Error
185
1)
Analog samples missing
1) Used for software simulation
